Storage systems are now increasingly establishing as an important technical solution to match to photovoltaic systems to improve their performances and use of energy.
The need of using the solar energy even when the sun is not present entailed the technological research as well as technical solutions that allowed to guarantee energy autonomy even in isolated situations, especially in off-grid plants.
Today there are a new market and new conditions thanks to the definition of clear rules and well-established technologies, given also by the introduction of lithium batteries, which guarantee high performances and high energy availability.
VP Solar: your specialized distributor of storage systems
When talking about storage, we are not only dealing with storage batteries, but it is always more important to talk about an overall system which allows to get the maximum from the energy produced and the right and highest efficiency in the management of the energy flow from and towards the building through an efficient and punctual management.
The electricity grid is fundamental in a storage system, not only to guarantee continuity if the battery or the PV plant cannot do it, but also because it is a big storage of energy able to collect it once the accumulation has been completely charged, especially during the summer.
Thanks to the connection to the grid that energy is not irretrievably lost, but it is valorized through the net energy metering.
20 years of experience in the photovoltaic sector
Thanks to its 20-years’ experience in the field of off-grid systems, today VP Solar is the touchstone of storage systems, since it selects and brings the most efficient and reliable technical solutions to the market.
This allows its customers, both resellers and installers, to propose advanced technological systems allowing to save a lot of money on the bills.
New Storage Map 2021
This document is in table format and defines the possible combinations between inverters and photovoltaic storage batteries available on the market.
The table also shows a series of technical data useful for the design and choice of a “standard” residential and commercial storage system.
-
BYD, Storage Battery
BYD: Battery-Box Premium HVS / HVM – high voltage – from 5.1 to 66.2 kWh
The new high voltage batteries of the BYD brand are devices compatible with many single-phase and three-phase inverter brands.
BATTERY-BOX PREMIUM HVS
- composed of 2 to 5 HVS battery modules
- capacity of 5.1 to 12.8 kWh
BATTERY-BOX PREMIUM HVM
- composed of 3 to 8 HVM battery modules
- capacity of 8.3 to 22.1 kWh
SKU: n/a -
BYD, Storage Battery
BYD: Battery-Box Premium LVS – low voltage – from 3.8 kWh to 245.8 kWh
BYD Battery-Box Premium LVS low voltage battery (48V) to be combined with various three-phase and single-phase inverters.
- Scalable from 4 kWh to 246 kWh
- Maximum Flexibility for any application with up to 64 Modules connected in parallel
- Capable of High-Powered Emergency-Backup and Off-Grid Function
- Patented Internal Plug Design Requires No Additional Wiring
SKU: n/a -
GoodWe, Storage Battery
GoodWe Lynx Home U – low voltage – from 5.4 kWh to 32.4 kWh
GoodWe’s Lynx Home U Series lithium batteries are low voltage batteries designed for residential applications.
- Nominal voltage of 51.2V
- Compatible with GW xx00 S-BP, GW xx48-EM
- 10 Years warranty
- Available sizes: 5.4 / 10.8 / 16.2 / 21.6 / 27 / 32.4 kWh;
SKU: n/a -
Huawei, Storage Battery
Huawei LUNA2000 – smart string battery – 5/10/15 kWh
Lithium batteries for photovoltaic storage. Modular system with 5 kWh stackable battery packs with 100% discharge capacity.
- Modular design of 5kWh, 10 kWh and 15 kWh and parallelable up to 2 systems for a total of 30 kWh
- 10 year guarantee
- Configurable with Huawei Hybrid Single and Three Phase Inverters
SKU: n/a -
Huawei, Storage Battery
Huawei LUNA2000-7/14/21-S1
Storage system with 6.9 kWh LFP cells, modular solution with the possibility of stacking up to three battery packs per tower with a maximum capacity of 20.7 kWh parallelable up to 4 towers for a total of 82.8 kWh.
Huawei inverter compatible batteries:
- SUN2000-12/15/17/20/25K-MB0
- SUN2000-3/4/5/6/8/10KTL-M1
- SUN2000-2/3/3.68/4/4.6/5/6KTL-L1
SKU: n/a -
Jinko Solar, Storage Battery
Jinko Solar: Sungiga – all-in-one cabinet for C&I applications
The Sungiga JKS-215KLAA-100PLAA is an all-in-one energy storage solution which packs battery modules, BMS, PCS, fire suppression systems and liquid cooling in a single cabinet.
- Capacity: 215 kWh
- Charge/discharge power: 100 kW
- Liquid cooling
- Integrated fire suppression system
- IP 55
- Cloud-based monitoring
SKU: n/a -
LG Energy Solution, Storage Battery
LG Energy Solution PRIME – high voltage – 10H/16H
LG PRIME offers maximum safety for electricity consumption regardless of external uncertainties, achieving energy independence through the conservation of self-produced and eco-friendly solar energy.
- It works in temperatures ranging from -10°C to 50°C, so it is suitable for any type of weather conditions.
- The installation can be done both on the wall and on the floor.
- Available sizes: PRIME 10H, PRIME 16H.
SKU: n/a -
LG Energy Solution, Storage Battery
LG Energy Solution RESU – low voltage – 6.5/10/12
LG Energy Solution with RESU battery packs 48 V provides the most advanced solution in the market with regard to lithium-ion view the best energy density, high quality and reliability.
Three levels of basic skills from 6.5 kWh, 9.8 kWh and 13.1 kWh with expandability up to 26,2 kWh.
- Compact size and easy installation
- Better energy density in the world
- Tested safety
SKU: n/a -
LG Energy Solution, Storage Battery
LG Energy Solution RESU – high voltage – 10M
High-voltage residential battery with modular design consisting of two battery modules and a BPU (Battery Protection Unit), which make it extremely handy and easy to install.
- battery module weight 36Kg, total weight with all three parts combined 80 kg
- extremely small size: base 45cm x height 51cm and 24cm deep
- compatible with Sunny Boy Storage 3.7 inverters
- RESU10M energy 9.8 kWh
SKU: n/a -
Pylontech, Storage Battery
Pylontech H48050A lithium battery HIGH voltage
The Pylontech H48050A lithium battery is the module that connected in series allows to obtain storage systems with different types of working voltages and storage capacity, depending on the application. The system consists of a control module and several battery modules.
- 4.8 kWh energy for single-phase systems and 9.6 kWh for three-phase systems
SKU: n/a -
Pylontech, Storage Battery
Pylontech RACK CABINETS
Pylontech Rack cabinets painted with polyester powder, suitable for Pylontech batteries.
- Single section cabinet painted in polyester powder, embossed finish with ventilation grilles in RAL 5011 and RAL 5021
- Adjustable feet kit for wardrobe
- Pylontech / inverter connection cables kit
- Back brackets for battery support included for cabinets from 9U to 42U
SKU: n/a -
Pylontech, Storage Battery
Pylontech US2000 lithium battery
The Pylontech US2000 lithium battery module is suitable for making small and medium capacity storage systems.
- From 2.4 kWh
- Up to 16 units without parallel module.
- Modular to create storage systems even of large dimensions.
- Soft-start mode: reduces the peak current when the inverter has to start with only one battery.
SKU: n/a -
Pylontech, Storage Battery
Pylontech US3000 – lithium technology – low voltage
Pylontech US3000 lithium batteries, 3.55 kWh modules, maximum instantaneous charge and discharge power and depth of discharge up to 95%.
- 10 year warranty
- Longer life cycle, exceeding 6000 cycles
- Internal molecular structure of LFP batteries
- Compact and modular design
- Soft-start mode : reduces the peak current when the inverter must start with only one battery
SKU: n/a -
SolarEdge, Storage Battery
SolarEdge Energy Bank – high voltage – 10 kWh
Photovoltaic energy storage batteries with Li-ion NMC technology, nominal capacity of 10.3 kWh (100% DOD, effective capacity of 9.7 kWh).
- NMC 9.7kWh / 5kW Li-ion technology
- Support up to 3 batteries per inverter for more power and capacity 100% depth of discharge
- 10 year guarantee
SKU: n/a -
-
Storage Battery, Sungrow
Sungrow SBR – high voltage – from 9.6 to 102 kWh
High voltage lithium iron phosphate LFP batteries, modular and expandable at any time, with 10 years warranty and parallelable up to 4 units.
- They can charge and discharge with a maximum current of 30A
- Equipped with a charge status indicator
- IP55, can be installed both indoors and outdoors
- Protection from abnormal voltages and currents
- Available: SBR096 / SBR128 / SBR160/ SBR192 / SBR224 / SBR256
SKU: n/a -
Storage Battery, ZCS Azzurro
ZCS Azzurro: battery H48050 – high voltage – from 2,1 to 51,8 kWh
The H48050 batteries are 2.4 kWh modules that can be used with the ZCS three-phase hybrid inverters, in combination with the SC500-H or SC1000-H BMS.
- LFP technology
- Total net capacity (single module): 2,4 kWh
- Maximum charge and discharge current: 25 A
- Module weight: 24 kg
- 10-year warranty
SKU: n/a -
Storage Battery, ZCS Azzurro
ZCS Azzurro: HV ZBT 5K – high voltage – from 5.12 kWh to 20.48 kWh
The high voltage batteries of the HV ZBT 5K series constitute a stackable system compatible with the ZCS three-phase hybrid inverters and the EasyPower all-in-one single-phase system.
- LFP batteries
- Nominal capacity (single module): 5,12 kWh
- Stackable system (up to 4 modules in parallel)
- Nominal voltage: 400 V
- Weight (single module): 50kg
- Warranty: 10 years
SKU: n/a -
Storage Battery, ZCS Azzurro
ZCS Azzurro: LV ZSX5000 PRO battery – low voltage – from 4,6 to 18,4 kWh
Storage Battery, ZCS AzzurroZCS Azzurro: LV ZSX5000 PRO battery – low voltage – from 4,6 to 18,4 kWh
The ZSX5000 PRO LV battery modules are an energy storage unit for residential applications, combined with ZCS single-phase inverters.
- LFP technology
- Total net capacity (single module): 4,6 kWh
- Nominal voltage (single module): 51,2 V
- Maximum charge and discharge current: 100 A
- 10-year warranty
SKU: n/a -
Storage Battery, ZCS Azzurro
ZCS Azzurro: Power Magic – all-in-one cabinet for C&I applications
The outdoor retrofit Power Magic storage system is ideal for large-scale industrial installations. It can be adapted to the needs of each customer and installation is simple, thanks to the plug & play design.
- Capacity: 215 – 258 kWh
- Charge/discharge power: 125 kW
- Liquid cooling
- Integrated fire suppression system
- IP55
- Integrated EMS and monitoring
SKU: n/a -
Hybrid inverter, Inverter, Photovoltaic inverter, Residential Inverter ZCS Azzurro, Storage Battery, ZCS Azzurro, ZCS Azzurro, ZCS Azzurro
ZCS Azzurro: single-phase all-in-one hybrid – EasyPower HYD 3000/3680/4000/4600/5000/6000 ZP1
Hybrid inverter, Inverter, Photovoltaic inverter, Residential Inverter ZCS Azzurro, Storage Battery, ZCS Azzurro, ZCS Azzurro, ZCS AzzurroZCS Azzurro: single-phase all-in-one hybrid – EasyPower HYD 3000/3680/4000/4600/5000/6000 ZP1
The all-in-one EasyPower system is composed of a ZP1 single-phase inverter paired with HV ZBT batteries. It features a compact design and an extremely small size.
- 2 MPPTs
- Paired with HV ZBT batteries
- Backup function
- Integrated DC circuit breaker
- RS485, USB, Bluetooth, CAN 2.0 (battery connection), Optional: WiFi/4G/Ethernet
- 10-year warranty
- Available sizes: HYD 3000-ZP1, HYD 4000-ZP1, HYD 5000-ZP1, HYD 6000-ZP1
SKU: n/a -
Storage Battery, ZCS Azzurro
ZCS Azzurro: US5000 battery – low voltage – from 4,3 to 21,5 kWh
The US5000 batteries are a modular storage solution that can be used with ZCS single-phase inverters.
- LFP technology
- Total net capacity (single module): 4,3 kWh
- Nominal voltage (single module): 48 V
- Maximum charge and discharge current: 80 A
- 10-year warranty
SKU: n/a -
Storage Battery, ZCS Azzurro
ZCS Azzurro: WECO 5K3 XP battery – 5,8 kWh
The WECO 5K3 XP battery is a stackable module that can be used with both single-phase ZCS inverters, HYD3000/6000 ZSS-HP, 3000SP and three-phase ZCS inverters, ZCS HYD 5000/8000 ZSS e HYD 10000/20000 ZSS.
- LFP technology
- Nominal capacity (single module): 5,8 kWh
- Nominal voltage (single module): 51,2 V
- Maximum charge and discharge current: 100 A
- Operating cycles: 7000
- 10-year warranty
SKU: n/a
Storage Guide 2020
VP Solar to help installers in the choice and combination of components for a photovoltaic system with storage, has created a Storage Guide 2020 with a comparative table of systems.
The guide introduces various manufacturers of storage batteries and inverters and presents the market news.
In brief some of the topics you can find in the book:
- The type of inverter: hybrid, PV or retrofit
- The connection of the battery to the grid: AC, DC side or both
- Grid connection: single-phase or three-phase
- The system configuration: all-in-one or composed of several components
- Backup function
The book is available in three different languages, English, Spanish and French
Contact us for further information and register to our Private Area to know VP Solar’s solutions in detail!
