Overview of Goodwe inverters

Goodwe, an innovative company in the photovoltaic sector, is committed to driving the future toward an intelligent and sustainable energy transition. Thanks to its role as an active participant in the international market, the company has reached a total installed capacity of 71.2 GW globally.

Let’s take a look at their inverters available for the residential market.

Residential and hybrid products in Goodwe’s portfolio

ES – EM – BP Series

The ES, EM, and BP series are single-phase inverters for residential installations. They are available in two sizes: GW3648D and GW5048D. Let’s look at the distinguishing features between these products:

ES: hybrid inverter that can be connected to photovoltaic systems and batteries on the DC side. On the AC side, it offers the backup function. The battery charge and discharge power is matched to the sizes of the product.
EM: hybrid inverter with a smaller capacity than the ES series, and a lower battery charge/discharge power (up to 2000 watts).
BP: retrofit inverter, without photovoltaic input, designed to be integrated into existing systems that require the addition of an energy storage system.

These series are compatible with low-voltage batteries (up to 48V), such as the Lynx Home U 5.4L battery. Each inverter can support up to 6 towers in parallel, reaching a total capacity of 32.4 kWh.

EH – EH+ Series

These are also single-phase hybrid inverters for residential installations, available in three different sizes: GW3600(N), GW5000(N), GW6000(N). The fundamental difference between these two types of inverters lies in the input current:

EH: input current of 14 amps.
EH+: input current of 16 amps, which allows the use of modules with higher currents in residential systems.

These series are compatible with high-voltage batteries (from 85 to 450 V), such as the Lynx F/F+ 6.6-16.4 kWh. Each EH or EH+ inverter can support up to 8 towers with 5 battery modules each, for a total capacity of 130 kWh.

ET – BT Series

These are three-phase inverters for residential and small commercial installations, available in four sizes: GW5000-6000-8000-10000.

ET: three-phase hybrid inverter that can be connected to photovoltaic systems and batteries on the DC side, also featuring AC-side backup output.
BT: retrofit inverter without photovoltaic input, designed to be integrated into existing systems that require the addition of an energy storage system.

Like the previous series, these inverters are compatible with high-voltage batteries (from 85 to 450 V) such as the Lynx F/F+ 6.6-16.4 kWh. Each ET or BT inverter can support up to 8 towers with 5 battery modules each, reaching a total capacity of 130 kWh.

All of Goodwe’s hybrid inverters, both single-phase and three-phase, are equipped with the following accessories:
